| Flame Retardant |
H > 제품소개 > Flame Retardant |
|
|
|
| Lubrizol’s Estane Engineered Polymers offer zero halogen flame-retardant compounds which combine good mechanical properties and processing. For some specific applications in building and construction environments and mass transit construction, flame retardancy and low-smoke fire materials are necessary. Lubrizol offers aselection of halogenated and non-halogenated flame retardant compounds for cable jacketing materials, injections molded parts and other extrusion profiles. |
|
 Benefits of Estane Engineered Polymers |
|
| In the last decade, environmental groups have lobbied increasingly to bring down the emissions of carcinogenic dioxins and halogens, as well as to decrease the presence of certain stabilizers, plasticizers and flame retardants. This has had its effects on the use of PVC in the wire and cable industry, as well as halogenated flame retardants in thermoplastic polyurethanes(TPUs). The European Union has shifted its focus to non-halogenated flame-retardant compounds in legislation and for specifications. The European cable specifications are less stringent on standards for ignitability and flame propagation to attain the objective of “Zero Halogen/Low Smoke.” |
|
| Lubrizol is responding to this challenge by continuing to develop and introduce Estane Engineered Polymers with zero halogen content while maintaining the essential mechanical and processing properties inherent to TPUs and other engineered polymers. |
|
| Markets |
| Industrial |
| Building/Construction |
| Military |
| Automotive |
| Telecommunication |
| Mining |
| Mass Transit |
| Alternative Energy |
| Marine |
| Oil & Gas |
|
 |
|
|
| Product specifications |
|
Product
family |
Product |
Hardness |
Finish |
UL Vertical
Burn Rating |
Mechanical
(Tensile) |
Low smoke
(Yes or No) |
Comment |
| Halogen |
58370 |
80A |
matte |
V2/LOI25 |
High |
No |
Low-Temperature Flexibility |
| 58202 |
85A |
matte |
V0/LOI30 |
High |
No |
Industry Standard |
| 58211 |
90A |
matte |
V0/LOI32 |
High |
No |
Standard Grade |
| HFR85AT3 |
85A |
matte |
V0/LOI30 |
High |
No |
Industry Standard |
| Non-Halogen |
ZHF 70AT3 |
70A |
matte |
V2/LOI25 |
High |
No |
Softest NHFR/silky matte |
| ZHF 75AT8 |
75A |
Gloss |
V2/LOI25 |
High |
No |
Soft |
| ZHF 78AT3 |
78A |
Gloss |
V2/LOI25 |
High |
No |
NHFR/Gloss |
| ZHF 82AT3 |
82A |
Gloss |
V2/LOI25 |
High |
No |
NHFR/Gloss |
| ZHF 85AT3 |
85A |
Gloss |
V2/LOI25 |
High |
No |
NHFR/Gloss |
| ZHF 85AT8 |
85A |
matte |
V2/LOI28 |
High |
No |
Excellnt FR performance/VW-1 |
| 58244 |
90A |
matte |
V2/LOI28 |
Average |
Yes |
Low smoke |
| ZHF 90AT2 |
90A |
matte |
V2/LOI25 |
High |
Yes |
Higher Mechanicals |
| ZHF 90AT3 |
90A |
matte |
V2/LOI28 |
High |
No |
Excellent FR performance/VW-1 |
| ZHF 95AT3 |
95A |
matte |
V0/LOI39 |
Average |
No |
High LOI |
| ZHF 85AB3 |
85A |
matte |
V0/LOI28 |
High |
No |
High mechanical/silky matte |
| ZHF 90AB3 |
90A |
matte |
V0/LOI28 |
High |
No |
High mechanical/silky matte |
| EXP ZHF 85AP3 |
85A |
matte |
V0/LOI26 |
High |
No |
High heating resistance/high chemical resistance |
|
| All marks are owned by The Lubrizol Corporation. |
